admin2024-07-04 13:03:272024-07-04 13:05:49京东方MLED BTT 天同高端系列京东方MLED BRY-A/B 睿翼系列
基本情况
- 适用模组磁铁工程
- 适用高端商显场景
- 安装快捷，方便拆卸
- 极致简约，节能设计
- 化繁为简，高集成一体化
产品参数:
| 规格参数 | BRY012A1/A2 | BRY015A1/A2 | BRY018A1/A2 | BRY020A1/A2 | BRY025A1/A2 |
| 像素间距（mm） | 1.25 | 1.538 | 1.86 | 2.0 | 2.5 |
| 像素密度（点/㎡） | 640,000 | 422,500 | 288,906 | 250,000 | 160,000 |
| 整机尺寸（mm） | 640*320*50/ 320*320*50（最薄处19mm） | ||||
| 单机重量（Kg） | ≤4 | ||||
| 颜色处理深度（Bit） | 14Bit | ||||
| 刷新频率（Hz） | ≥3840 | ||||
| 驱动方式 | 1/64 | 1/52 | 1/43 | 1/40 | 1/64 |
| 亮度（cd/㎡） | ≥450（可调） | ||||
| 交流输入电压（V） | AC100~240±10%(50/60Hz) | ||||
| 交流输入功率最大值（W/m²） | 318W/m² | ||||
| 交流输入功率典型值（W/m²） | 105W/m² | ||||
| 产品防护等级 | IP30 | ||||
| 箱体安装方式 | 前/后安装 | ||||
| 箱体维护方式 | 前/后维护 | ||||
